Stepper motor

20-frame stepper motor

20-frame two-phase hybrid stepper motor for the MSP20 integrated drive. Open loop, closed loop, brake, and gearbox are selected in the configurator.

Stepper motor outline
Stepper outline. Mounting holes and shaft extension for this frame are confirmed with the order.
  • 20Frame
  • Two-phase 1.8°Stepper
  • Open / closed loopOptional
  • MSP20Matched code
Integrated stepper drive

Mounting check

This frame is for light-duty positioning. Mounting holes, shaft extension, and inertia are issued after the project is confirmed.

Wiring and supply: See Integrated stepper drive supported-motor table.

Engineering documents

Dimension drawings, 3D models, and the complete manual are supplied on request. This page does not offer downloads. with the model and the documents you need.

Matched drive

This frame pairs with MSP20. Supply, wiring, and software entry are on the drive page. Open loop, closed loop, brake, and gearbox are selected in the configurator.
